2356100 – Water Resistant 100A Busbar with CoverWater-resistant bussing for harsh environments. Built with wing screws for toolless access.Features:
- Accepts a wide range of wire sizes
- Includes 3 wire plugs to maintain a water-resistant rating if less than 4 wires are used
- Nests with other water-resistant 100A common busbars and ST-Blade water resistant fuse block for space-saving wiring
- Ideal for positive distribution and for the collection of negative or AC ground circuits
- Meets ABYC/USCG insulation requirements
- Tin-plated copper busses and fuse clips
- Includes four (4) write-on circuit labels
- Small format standard and custom labels are available
- Wing-screws designed for tool-free installation of cover to meet ABYC compliance
Technical Specifications:
- Cover – yes
- Maximum Voltage – 300V AC – 48V DC
- Terminal Stud – 1 x 10-32
- Continuous Rating – 100A AC or DC
- Bus Material – Tin-plated Copper
- Mounting Holes – Accepts 1/4″ (6mm) screws
- Terminal Screws – 4 x 8-32
- Wire Size – Input – (1) 8 AWG to 4 AWG
- Wire Size – Load – (4) 16 AWG to 10 AWG
In the Box:
- 2356100 Busbar
- Instruction Manual
*Sold as an Individual
