New Blue Sea Systems ST Blade fuse block with 6 independent circuits and cover. Accepts ATO or ATC fuses from 1A to 30A. Part number 5035.
Features
- Corrosion resistant, tin-plated copper fuse clips reduce heat and improve the efficiency of the electrical system
- Clear insulating cover with label recesses
- Accepts Blue Sea Small Format Labels for circuit identification (blank silver labels included for writing on — optional Blue Sea part 8214 black labels shown in picture)
- Spare fuse holder in cover
- Accepts ring or snap fork type terminals
- Includes two terminal block jumpers
Specifications
- Circuits: 6
- Maximum Amperage: 30A per circuit, 40A per jumped circuit group
- Maximum Voltage: 32V DC
- Mounting: 8 Screw (M4)
- Screw Terminal Type: 8-32 with Captive Star Lockwasher
- Weight: 0.35lb (0.16 kg)
