Boat part number 8305221 is a new breaker panel for a Crestliner 2100 Raptor, part number 2336999 . Year unavailable.
This dash shroud is constructed out of 1/8″ thick black marine plastic with a matte finish. Measures approximately 6 1/8″ L x 3 7/8″ H overall. Features 6-position fuse block and uses (1) 15-pin female, and bullet wire leads connections. Mounts with (6) 3/16″ dia. holes set apart 2 7/8″ x 3 3/8″ center to center.
This dash panel also features the following push button breakers:
- (1) 5 Amp: “Nav/Anc”
- (1) 3 Amp: “Livewell / Baitwell”
- (1) 3 Amp: “Aft Livewell”
- (1) 5 Amp: “Horn”
- (1) 10 Amp: “Acc”
- (1) 5 Amp: “CTSY”
- (1) 20 Amp: “Wash Down”
- (1) 3 Amp: “Recirc”
- (2) 15 Amp: “12 V”
Specifications
- Boat Manufacturer: Crestliner
- Model: 2100 Raptor
- Year: Unavailable
- Part Number: 2336999
- Material: Marine Grade Plastic
- Color: Black
- Finish: Matte
- Overall Dimensions: 6 1/8″ L x 3 7/8″ H
- Connections: (1) 15-Pin Female | Wire Leads
- Mounts: (6) 3/16″ Dia. Holes Set Apart 2 7/8″ x 3 3/8″ CTC
