The Dickinson Marine Radex Double Water Heat Exchanger (00-RAD2) from Nomadic Supply Company® is a genuine Dickinson Marine replacement part designed for the Dickinson Marine Newport Diesel Bulkhead Mount Heater (00-NEW), Dickinson Marine Alaska Diesel Floormount Heater (00-ALA), Dickinson Marine Antarctic Diesel Floormount Heater (00-ANT), and Dickinson Marine Lofoten Diesel Floormount Heater (00-LOF).
Dickinson Marine Radex Double Water Heat Exchanger (00-RAD2) Features:
- Double Heating Capacity. The Dickinson Marine Radex Double Water Heat Exchanger (00-RAD2) delivers up to 24,000 BTU of heating power, providing twice the capacity of the single Radex unit for larger cabin spaces and higher heat demand applications.
- Efficient Waste Heat Conversion. The Dickinson Marine Radex Double Water Heat Exchanger (00-RAD2) efficiently converts waste water heat from a water-cooled engine or hot water system into warm air, providing a continuous supply of temperate cabin heat without additional fuel consumption.
- Corrosion-Resistant Stainless Steel. The Dickinson Marine Radex Double Water Heat Exchanger (00-RAD2) is constructed with high-quality stainless steel that is highly resistant to corrosion and requires minimal maintenance over its service life.
- Simple Installation. The Dickinson Marine Radex Double Water Heat Exchanger (00-RAD2) connects directly to a circulating source of hot water and a low-voltage power supply, making installation straightforward with no complex plumbing required.
- Engine Coolant Compatible. The Dickinson Marine Radex Double Water Heat Exchanger (00-RAD2) can harness wasted energy from engine coolant to provide dry, clean cabin heat, making it an efficient supplement to primary heating systems.
- Flexible Mounting Options. The Dickinson Marine Radex Double Water Heat Exchanger (00-RAD2) supports both side mount and frame mount configurations, allowing installation in the orientation that best suits the available space.
- Multi-Application Versatility. The Dickinson Marine Radex Double Water Heat Exchanger (00-RAD2) is ideal for a variety of applications including boats, RVs, trucks, and cars, providing versatile supplemental heating wherever hot water circulation is available.
Dickinson Marine Radex Double Water Heat Exchanger (00-RAD2) Specifications:
- Heat Output: 24,000 BTU (Based on 100°F Temperature Rise)
- Power: 12V Dual Fan
- Material: Stainless Steel
- Mounting: Side Mount or Frame Mount
- Width: 16.75″
- Height: 7″
- Depth: 5″
- Weight: 10 lbs
- Heat Source: Hot Water (Engine Coolant or Hot Water System)
- Applications: Boats, RVs, Trucks, Cars
- SKU: 00-RAD2
