Boat part number 8601963 is a new 4-position outboard push to choke ignition switch panel manufacturer unavailable, part number AD-050-488 . Commonly used on Larson Boats, part number 2207-2165 . May be used on other boats.
This switch panel is constructed out of brushed gray marine grade plastic with a glossy finish. Measuring approximately 7 3/4″ W x 3″ H overall, and has (6) approximately 1/8″ Dia. mounting holes around perimeter of panel.
This ignition switch panel features the following:
- (1) Horn push-button breaker
- (4) Push-button breakers
- (1) NAV / ANC (On/Off/On rocker switch)
- (1) Bilge (On/Off rocker switch)
- (1) ACC / Courtsey (On/Off/On rocker switch
- (1) 4-position (Push-to-choke ignition switch with 2 keys)
This ignition switch panel connects with the following:
- (1) 6 Pin Female
- (1) 4 Pin Female
- (2) 2 Pin Male
- (1) 12 Pin Male
- (1) 8 Pin Male
- (1) 2 Pin Female
- (3) Single Plug Female
Specifications:
- Boat Manufacturer: Larson
- Part Number: 2207-2165
- Part Manufacturer: Unavailable
- Part Number: AD-050-488
- Material: Marine Grade Plastic
- Color: Gray
- Finish: Glossy
- Overall Dimensions: 7 3/4″ W x 3″ H
- Mounts: (6) 1/8″ Dia. Holes
- Connection: (1) 6 Pin Female / (1) 4 Pin Female / (2) 2 Pin Male / (1) 12 Pin Male / (1) 8 Pin Male / (1) 2 Pin Female / (3) Single Plug Female
