Boat part number 1077575 is a new blank dash panel for a Premier Pontoon boat, part number unavailable. Manufactured by MNStar Technologies, part number 00-8215 .
Constructed out of marine grade plastic with a woodgrain appearance, this panel measures approximately 24 1/8″ W (tapers to 19″ W) x 7 3/8″ H x 8 3/4″ D overall. Features (1) momentary Horn button and (7) illuminated toggle switches. Uses (1) 2-pin female Deutsch, (1) 12-pin female Deutsch, (1) 12-pin male Deutsch, and (1) 3-pin male triangular connections.
Manufacturer label reads: 00-8215 2 Hole Dash Imperial Hickory
Hosts the following cutouts:
- (1) 4 5/8″ L x 4 3/8″ (Display)
- (2) 3 3/8″ Dia. (Gauges)
Specifications:
- Boat Manufacturer: Premier Pontoons
- Model/Year: Unavailable
- Part Manufacturer: MNStar Technologies
- Part Number: 00-8215
- Material: Plastic
- Color: “Imperial Hickory” Faux Woodgrain
- Finish: Matte
- Overall Dimensions: 24 1/8″ L x 7 3/8″ H x 8 3/4″ D
- Cutouts: (1) 4 5/8″ L x 4 3/8″ | (2) 3 3/8″ Dia.
- Connections: (1) 2-Pin Female Deutsch | (1) 12-Pin Female Deutsch | (1) 12-Pin Male Deutsch | (1) 3-Pin Male Triangular
