Boat part number 1086437 is a new blank starboard side console panel for Z119 / Z519 model Ranger Boats, part number 7202282-S .
This side console panel is constructed out of plastic with dark gray faux leather vinyl covering and measures approximately 29 1/4″ L x 12 5/8″ H x 7 1/4″ D overall. It has (11) 1/8″ Dia. mounting holes (hardware not included).
It has the following cutouts and indents:
- (1) 3″ Dia.
- (1) 1 3/4″ Dia.
- (1) 8 7/8″ L x 6 5/8″ H
- (1) 5″ L x 4 1/2″ H (tapers down to 1 1/2″ H)
Specifications:
- Boat Manufacturer: Ranger Boats
- Model: Z119 / Z519
- Part Number: 7202282-S
- Part Manufacturer: Unavailable
- Material: Plastic / Vinyl
- Color: Dark Gray
- Finish: Faux Leather
- Overall Dimensions: 29 1/4″ L x 12 5/8″ H x 7 1/4″ D
- Mounts: (11) 1/8″ Dia. Holes
