The Victron Energy Orion-Tr Smart 48/12-20A (240W) Isolated DC-DC charger (ORI481224120) from Nomadic Supply Company® is an isolated DC-DC charger with Bluetooth connectivity, delivering programmable three-stage charging (bulk, absorption, float) for optimal battery charging from 48-volt sources to 12-volt systems. With 240-watt continuous power, Bluetooth monitoring, and eight pre-programmed battery profiles, it combines intelligent charging with system flexibility.
Victron Energy Orion-Tr Smart 48/12-20A (240W) Isolated DC-DC charger (ORI481224120) Features:
- Isolated DC-DC charger with Bluetooth Smart connectivity
- Three-stage charging algorithm: Bulk, Absorption, Float
- Programmable via Victron Connect smartphone app
- Eight pre-programmed battery chemistry settings
- Automatic absorption time calculation for efficient charging
- Input voltage range 32-70V DC with lock-out protection
- Output voltage adjustable 10-15V for battery compatibility
- Continuous 30A output with 360W power rating
- Remote on-off capability for engine-dependent operation
- Automatic engine shutdown detection via D+ input
Victron Energy Orion-Tr Smart 48/12-20A (240W) Isolated DC-DC charger (ORI481224120) Specifications:
| Input Voltage Range | 32-70V DC |
| Under Voltage Shutdown | 28V |
| Under Voltage Restart | 30V |
| Output Voltage Range | 10-15V (adjustable) |
| Nominal Output Voltage | 12.2V |
| Continuous Output Current (40°C) | 30A |
| Maximum Output Current (10s) | 40A |
| Continuous Power (25°C) | 430W |
| Continuous Power (40°C) | 360W |
| Efficiency | 87% |
| Connectivity | Bluetooth Smart |
Victron Energy Orion-Tr Smart 48/12-20A (240W) Isolated DC-DC charger (ORI481224120) Documents:
Victron Energy Orion-Tr Smart 48/12-20A (240W) Isolated DC-DC charger (ORI481224120) Owner’s Manual
