The Victron Energy Phoenix Inverter 48/500 120V VE.Direct NEMA 5-15R (PIN485010500) from Nomadic Supply Company® is 48V to 120V pure sine wave inverter delivering 500VA continuous power with NEMA 5-15R standard receptacle. VE.Direct communication provides full system monitoring and configuration capability. Engineered for larger battery systems requiring consistent high-quality AC power output.
Victron Energy Phoenix Inverter 48/500 120V VE.Direct NEMA 5-15R (PIN485010500) Features:
- Pure sine wave output at 120V, 500VA capacity
- VE.Direct communication port for monitoring and control
- NEMA 5-15R standard receptacle
- Maximum efficiency of 90%
- Eco mode capability
- IP21 protection rating
- User-adjustable settings
- Configurable low battery alarm and cut-off
- Suitable for marine and off-grid applications
- Peak power output of 900W
Victron Energy Phoenix Inverter 48/500 120V VE.Direct NEMA 5-15R (PIN485010500) Includes:
- Inverter unit
Victron Energy Phoenix Inverter 48/500 120V VE.Direct NEMA 5-15R (PIN485010500) Specifications:
| Continuous Power @ 25°C | 500VA / 400W |
| Continuous Power @ 40°C | 350W |
| Peak Power | 900W |
| Input Voltage Range | 36.8 – 62.0V DC |
| Output Voltage | 120VAC ±3% |
| Output Frequency | 50/60Hz (selectable) |
| Maximum Efficiency | 90% |
| Zero-Load Power | 9.0W (2.5W in ECO mode) |
| Dimensions | 3.4″ H × 6.8″ W × 10.8″ D |
| Weight | 8.5 lbs |
| Protection Rating | IP21 |
| DC Cable Size | 8 AWG maximum |
Victron Energy Phoenix Inverter 48/500 120V VE.Direct NEMA 5-15R (PIN485010500) Documents:
Phoenix Inverter VE.Direct 250–1600VA DatasheetVictron Energy Phoenix Inverter 48/500 120V VE.Direct NEMA 5-15R (PIN485010500) Owner’s Manual
