The Victron Energy SmartSolar MPPT RS 450/200-Tr Solar Charge Controller (SCC145120410) from Nomadic Supply Company® is the ultimate high-voltage isolated charge controller for massive 48V systems. With 200A output at 450V input and VE.Can networking, this controller manages 11.52kW systems for the most demanding applications. Isolated topology ensures maximum flexibility and protection.
Victron Energy SmartSolar MPPT RS 450/200-Tr Solar Charge Controller (SCC145120410) Features:
- Isolated MPPT topology for maximum protection
- 450V maximum solar input voltage
- 200A charging output for 48V systems
- VE.Can connectivity for multi-unit systems
- Screw-terminal connections for robust wiring
- Programmable relay for automation
- Remote temperature and voltage sensing
- Daisy-chain up to 25 units for large arrays
- BMS integration capability
- Active cooling system
Victron Energy SmartSolar MPPT RS 450/200-Tr Solar Charge Controller (SCC145120410) Specifications:
| Input Voltage Range | 65V – 450V DC |
| Output Voltage | 48V DC |
| Rated Charge Current | 200A |
| Maximum Power Output | 11.52kW |
| Efficiency | >98% |
| Cooling | Active fan cooling |
| Communication | VE.Can + Bluetooth |
| Connector Type | Screw Terminal |
| Operating Temperature | -30°C to 60°C |
| Synchronizable Units | Up to 25 units |
Victron Energy SmartSolar MPPT RS 450/200-Tr Solar Charge Controller (SCC145120410) Documents:
SmartSolar MPPT RS DatasheetSmartSolar MPPT RS ManualVictron Energy SmartSolar MPPT RS 450/200-Tr Solar Charge Controller (SCC145120410) Owner’s Manual
